CKT700series data logger adopt high-performance ARM microprocessor, it is 5.6 inches screen, can independently and blend collect the data of multi-channeltemperature, voltage, resistance and humidity. High/low beep function andcommunication transmission. Can be extended to 18channels, and is compatible with various temperature sensors. With 10msquick respond and stable data. Support RS-232 and USB communication, realizedata acquisition, analysis and print through the standard computer software.Support network communication and USB disk storage and store real-time samplingdata. The users can adjust data for each channel independently.
SPECIFICATIONS |
|
| CKT700 Data Logger |
Parameters | Thermocouple：J/K/T/E/S/N/B/R/W Thermal resistance: PT100/CU50/CU100/G53/BA1/BA2 DCV, Resistance, Humidity, Pressure, Current |
Basic Accuracy | 0.2℃±2 digits |
Resolution | 0.1℃ |
Measurement Range | -270C~1760℃（Resolution 0.1℃, varying depend on graduation） Voltage：-22.00mV~5.2V Resistance：0.001~400.00Ω Humidity：0%RH-100%RH (humidity sensors are optional) |
Speed | 10ms/10-channel |
Correction | Error correct for each channel |
Comparator | High/low beep Individual setting high/low value for each channel |
Interface | RS232C interface USB-disc interface |
Options | LAN interface |
Software | Data acquisition Software |
Protection | Max 300 VAC |
CJC | Accuracy：0.1℃ |
Others | 5.6 inches TFT-LCD with screen, true-color LCD display，broken thermocouple check function, U-disk storage |
GENERAL FEATURES |
|
Power Supply | Voltage：65VAC～240VAC 16V DC ~32VDC lithium battery powered |
Size | 260*340*320(mm) 4kg |
ORDERING INFORMATION |
|
Accessories | Data acquisition software |
